InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
13.1.1.31 Value: BusL curr L3
BusL current in phase L3.
NOTE:
The ratio between the current measured at the input terminals and the
displayed current is adjusted by the setpoints BusLeftCTprim and
BusLeftCTsec.
13.1.1.32 Value: BusL V unbal
BusL voltage unbalance. The value is calculated as maximal difference of
two phase voltages at one moment and expressed in % of the nominal
voltage.
NOTE:
This value can be used for creating the BusL voltage unbalance protection
using the "universal analog protections".
13.1.1.33 Value: BusL I unbal
BusL current unbalance. The value is calculated as maximal difference of two
phase currents at one moment and expressed in % of the nominal current.
NOTE:
This value can be used for creating the BusL current unbalance protection
using the "universal analog protections".
