Installing Subracks and PSUs in an Equipment Rack
Install SFP+ Transceivers in the OPT Cards
1 Followthestepsin"InstalltheCANandTENCards”onpage27toinstalltheOPTCardintotheWCS
Subrack,asneededforthisinstallation:
• CAT:SlotsL1-L8
• TEN:SlotR1
2 UsethesystemdesigntoidentifywhichOPTCardportswillbeusedinthissystem.
3 ObtaintherequirednumberofSFP+Transceivers.
4 SlidetheSFPintotheOPTCardportidentifiedinStep2,andpushtheSFPintotheOptCarduntilyouhear
itclickintoplace.
UNRESOLVED: Connect to what? R1.1 to CAN - otherwise? Cable?
Should you need to remove an SFP+ Transceiver, press down on its extraction lever, and then carefully pull
the transceiver out of the slot.
SFP+ Transceiver
Extracon lever
OPT Card Port 1
