CommScope ION-E Series User Manual

M0201AA ION
®
-E Series Hardware Installation Guide
© June 2017 CommScope, Inc. Page 57
Installing UAPs
12 Forsafety,theinstallationofhangerwirestoattachtheUAP'sTwo-PartSlidingSupportBarsto
permanentceilingstructuresisrecommended.
Attachhangerwires,accordingtolocalbuildingcodesfromtheroofstructuretotheholesatendsofthe
UAP'sTwo-PartSlidingSupportBars,asshownbelow.
Mounting a UAP Using a UAP Quick Release Ceiling Mount Kit
UNRESOLVED: What is the PN for this kit?
TheUAPquickreleaseceilingmountkitisdesignedtobeinstalledinastandard60cmx60cm(2'x2')
suspendedceilinggrid.Ifthegriduses120cmx60cm(4'x2')ceilingtiles,addanadditionalcross-runner
(cross-tee)tothemainrunnertosupporttheunit.Aminimumoverheadclearanceof70cmisrecommended.
UAPwallmountingkit7683181-00isalsoavailablefromCommScopeformountingaUAPtoawallorhard
ceiling.
Required Tools for a Quick Release Ceiling Mount Kit
• 8mmmetrictorquewrenchtosecuretheGuide-Lockpinsandthumbscrewlocknuts
• Cuttingtooltocutopenceilingtile
For information on mounting a UAP to a ceiling using the standard UAP ceiling mount, go to "Using the
UAP Ceiling Mount Assembly (PN 7683182-00)” on page 53.
Hanger wires connected to the pre-drilled holes
in the Two-Part Sliding Support Bars
Exploded view
