Installing UAPs
Unpack and Inspect the Quick Release Ceiling Mount Kit
1 Inspecttheexterioroftheshippingcontainer(s)forevidenceofroughhandlingthatmayhavedamaged
thecomponentsinthecontainer.
2 Unpackeachcontainerwhilecarefullycheckingthecontentsfordamageandverifywiththepackingslip.
Overview of Using a Quick Release Ceiling Mount Kit
TheUAPQuickReleaseCeilingMountkitisdesignedtobeinstalledinastandard60cmx60cm(2'x2')
suspendedceilinggrid.Ifthegriduses120cmx60cm(4'x2')ceilingtiles,addanadditionalcross-runner
(cross-tee)tothemainrunnertosupporttheunit.Aminimumoverheadclearanceof70cmisrecommended,
asshownbelow.
Table 6-3. Quick Release Ceiling Mount Kit (PN ???????-00)
Quantity Component Description Quantity Component Description
1
Template 1 each Left and Right UAP Recess Bar
1 each UAP Recess Shroud with Mounting
Bracket
4 Guide Lock Pins
It is the responsibility of the installer to ensure that the UAP is safely installed.
Recommended
overhead clearance
is 70 cm (27.6 in)
Y
X
Ceiling grid
6
0 cm min.
(23.6 in min.)
60 cm min. - 76 cm max.
(23.6 in min. - 29.9 in max.)
Z
