CommScope ION-E Series User Manual

M0201AA ION
®
-E Series Hardware Installation Guide
© June 2017 CommScope, Inc. Page 43
Chapter Topics Page
Power Supply Unit (PSU) .....................................................................................................................................................................................44
PSU Modules and Connectors ........................................................................................................................................................................44
12 Vdc Power Module LEDs............................................................................................................................................................................ 45
57 Vdc Power Module LEDs............................................................................................................................................................................ 46
Installing PSUs .....................................................................................................................................................................................................47
ThischapterprovidesaproductoverviewandinstallationinstructionsfortheION-ESeriesPowerSupply
Unit(PSU).
POWER SUPPLY UNIT (PSU)
5
