M0201AA ION
®
-E Series Hardware Installation Guide
© June 2017 CommScope, Inc. Page 41
e-POI Subrack and Component Specifications
E-POI SUBRACK AND COMPONENT SPECIFICATIONS
Table 4-1. e-POI Subrack Specifications
Parameter Specification Notes
Height x width x depth, mm 4U x 19" x 395
Weight, kg* 7.7
Operating temperature, °C -5 to +50 Support rails are required for rack mounting
Table 4-2. e-POI Module Specifications
Parameter Specification Notes
Operational frequency, MHz 300 to 2700
Attenuation, dB 30 ±2 698-2700 MHz
35.5 ±3.5 380-450 MHz
33.5 ±3.2 450-698 MHz
RF input power +46 dBm
PIM @ 2x20 Watts (3rd order) -153 dBc
Input voltage, Vdc / Power consumption 12/10 Watts
