M0201AA ION
®
-E Series Hardware Installation Guide
© June 2017 CommScope, Inc. Page 31
Installing Subracks and PSUs in an Equipment Rack
CascadedUAPS
ToconnectuptothreecascadedpairsofUAPstotheCATCardviaports1-4(onepairperportwith
oneportunused).
UAP,UAP-N25,andUAP-X:connecttheCATCardporttotheUAPMainport.
CAPL:connecttheCATCardporttotheCAPLOpticalPort2.
CascadedUAPsdonotsupportEthernetdevices.Othercombinationsofcascadedandnon-cascaded
UAPsarealsopossibleaslongasthetotalnumberofUAPsconnectedtoaCATCarddoesnotexceed
six.
UAP, UAP-N25
UAP-X
CAT Ports 1 - 3 to/from UAP Main port
CAT Ports 1 - 3 to/from CAP L Opcal Port 2
CAP L
