4.2.4 Losses
Losses are equivalent to 0.5% of Drive rated output across the range.
The following table lists the losses in kW and HP for all models, at 400 V
armature voltage.
The field rectifier is protected by fuses FS1, FS2, FS3 on the power
boards.
Before attempting to replace fuses FS1, FS2, FS3 the
supply voltages must be removed from the Drive and
left removed for at least 2 minutes.
4.2.5 Recommended Line Reactors
To avoid electrical interference and dI/dt stress, do not
operate without line reactors. The following table gives
typical values to achieve a notch depth of 50%. Where a
specific notch depth is required, values must be
calculated. Refer to IEC 61800-3 for details of
calculation of notching depth.
4.2.6 Field Current Rating
Drive type & model
Single Four Typical
motor ratings
Losses
Quadrant Quadrant
kW HP kW HP
M25 M25R 7.5 10 0.038 0.05
M45 M45R 15 20 0.075 0.1
M75 M75R 30 40 0.15 0.2
M105 M105R 37.5 50 0.19 0.25
M155 M155R 56 75 0.28 0.37
M210 M210R 75 100 0.38 0.5
M350 M350R 125 168 0.63 0.83
M420 M420R 150 201 0.75 1
M550 M550R 200 268 1.0 1.3
M700 M700R 250 335 1.3 1.7
M825 M825R 300 402 1.5 2
M900 M900R 340 456 1.7 2.3
M1200 M1200R 450 603 2.3 3
M1850 M1850R 750 1005 3.8 5
Drivetype&model LinereactorsLa,Lb,Lc (µH)
M25, M25R 200
M45, M45R 200
M75, M75R 100
M105, M105R 100
M155, M155R 75
M210, M210R 75
M350, M350R 35
M420, M420R 27
M550, M550R 25
M700, M700R 23
M825, M825R 19
M900, M900R 17
M1200, M1200R 13
M1850, M1850R 8.6
WARNING
CAUTION
Drivetype&
model
Field Current
Rating (A)
Fuse
FS1, FS2, FS3
M25, M25R 8 regulated
CT
Part number
3535-0010
M45, M45R 8 regulated
M75, M75R 8 regulated
M105, M105R 8 regulated
M155, M155R 8 regulated
M210, M210R 8 regulated
M350, M350R 10
CT
Part number
3535-0020
M420, M420R 10
M550, M550R 10
M700, M700R 10
M825, M825R 10
M900, M900R 20
M1200, M1200R 20
M1850, M1850R 20
