Menu 12: Programmable Thresholds
0 = healthy (normal)
1 = threshold exceeded
0 = healthy (normal)
1 = threshold exceeded
0 = default
1 = signal inverted
0=default
1 = signal inverted
12.01 Threshold 1 exceeded
RO Bit
ô
0or1
ð
12.02 Threshold 2 exceeded
RO Bit
ô
0or1
ð
12.03 Threshold 1 source
RW Uni
ô
0 ~ 1999
ð
+302
12.04 Threshold 1 level
RW Uni
ô
0 ~ 1000
ð
+000
12.05 Threshold 1 hysteresis
RW Uni
ô
0~255
ð
002
12.06 Invert threshold 1 output
RW Bit
ô
0or1
ð
0
12.07 Threshold 1 destination
RW Uni
ô
0 ~ 1999
ð
+000
12.08 Threshold 2 source
RW Uni
ô
0 ~ 1999
ð
+501
12.09 Threshold 2 level
RW Uni
ô
0 ~ 1000
ð
+000
12.10 Threshold 2 hysteresis
RW Uni
ô
0~255
ð
002
12.11 Invert threshold 2 output
RW Bit
ô
0or1
ð
0
12.12 Threshold 2 destination
RW Uni
ô
0 ~ 1999
ð
+000
