Control Techniques Mentor II User Manual

64 Mentor ll User Guide
www.controltechniques.com Issue Number: 12
Menu 09: Status Outputs
Status Output parameters define a parameter to be used as a source,
thereby defining the function of programmable output terminals.
Menu 09 contains three status source groupings, each of which can be
inverted. The two sources ST1 and ST2 can be combined in any
convenient configuration for output to terminals TB2-15 and TB2-16. The
second group selects from sources ST3, ST4, ST5 for output to TB2-17,
TB2-18, TB2-19 respectively, or source ST6 (relay output).
Delays 09.12 and 09.18 apply to status outputs ST1 and ST2 in 0 -> 1
transitions.
In 1 -> 0 transitions the effect is immediate, without delay.
09.01 Status 1 output
09.02 Status 2 output
09.03 Status 3 output
09.04 Status 4 output
09.05 Status 5 output
09.06 Status 6 output (relay)
RO Bit
ô
0or1
ð
09.07 Status 1 source 1
RW Uni
ô
0 ~ 1999
ð
+111
09.08 Invert status 1 source 1
RW Bit
ô
0or1
ð
0
09.09 Status 1 source 2
RW Uni
ô
0 ~ 1999
ð
000
09.10 Invert status 1 source 2
RW Bit
ô
0or1
ð
+000
09.11 Invert status 1 output
RW Bit
ô
0or1
ð
+000
09.12 Status 1 delay
RW Uni
ô
0~255
ð
0Sec
09.13 Status 2 source 1
RW Uni
ô
0 ~ 1999
ð
+1007
09.14 Invert status 2 source 1
RW Bit
ô
0or1
ð
0
09.15 Status 2 source 2
RW Uni
ô
0 ~ 1999
ð
000
09.16 Invert status 2 source 2
RW Bit
ô
0or1
ð
0
09.17 Invert status 2 output
RW Bit
ô
0or1
ð
0
09.18 Status 2 delay
RW Uni
ô
0~255
ð
0Sec
09.19 Status 3 source
RW Uni
ô
0 ~ 1999
ð
+1013
09.20 Invert status 3 output
RW Bit
ô
0or1
ð
0
09.21 Status 4 source
RW Uni
ô
0 ~ 1999
ð
+1003
