Control Techniques Mentor II User Manual

Mentor ll User Guide 63
Issue Number: 12 www.controltechniques.com
0 = not invert
1 = invert logic function
0 = not enable
1 = enable Inch Reverse
When 08.21 = 1, normal logic functions disabled, 08.31 can enable
Inch Rev.
0 = not enable
1 = enable Inch Forward
When 08.21 = 1, normal logic functions disabled, 08.32 can enable
Inch Fwd.
0 = not enable
1 = enable Run Reverse
When 08.21 = 1, normal logic functions disabled, 08.33 can enable
Run Rev.
0 = not enable
1 = enable Run Forward
When 08.21 = 1, normal logic functions disabled, 08.34 can enable Run
Fwd.
08.22 Invert input F2
08.23 Invert input F3
08.24 Invert input F4
08.25 Invert input F5
08.26 Invert input F6
08.27 Invert input F7
08.28 Invert input F8
08.29 Invert input F9
08.30 Invert input F10
RW Bit
ô
0or1
ð
0
08.31 Enable inch reverse
RW Bit
ô
0or1
ð
0
08.32 Enable inch forward
RW Bit
ô
0or1
ð
0
08.33 Enable run reverse
RW Bit
ô
0or1
ð
0
08.34 Enable run forward
RW Bit
ô
0or1
ð
0
