98 Mentor ll User Guide
www.controltechniques.com Issue Number: 12
12 Electromagnetic
Compatibility
General note on EMC data
The information given in this User Guide is derived from tests and
calculations on sample products. It is provided to assist in the correct
application of the product, and is believed to correctly reflect the
behaviour of the product when operated in accordance with the
instructions. The provision of this data does not form part of any contract
or undertaking. Where a statement of conformity is made with a specific
standard, the company takes all reasonable measures to ensure that its
products are in conformance. Where specific values are given these are
subject to normal engineering variations between samples of the same
product. They may also be affected by the operating environment and
details of the installation arrangement.
Immunity
Provided that the instructions in this User Guide are correctly
implemented, Mentor II Drives exhibit
excellent immunity to interference from sources outside the Drive unit.
For more detailed information, refer to the Mentor II EMC datasheet.
The Drive complies with the following international and European
harmonised standards for immunity.
The immunity is achieved without any additional measures such as
filters or suppressors. To ensure correct operation the wiring guidelines
specified in the product manual must be carefully adhered to.
All inductive components such as relays, contactors, electromagnetic
brakes, etc., associated with the Drive, must be fitted with appropriate
suppression, otherwise the immunity of the Drive may be exceeded.
Standard Type of immunity Test specification Application Level
EN 61000-4-2* Electrostatic discharge 6kV contact discharge
8kV air discharge
Module enclosure Level 3
(industrial)
IEC 801-3 Radio frequency
radiated field
10V/m prior to modulation
27 - 1000MHz
80% AM (1kHz) modulation
(reduce to 3V/m for 87-108MHz)
Module enclosure Level 3
(industrial)
ENV 50140* Radio frequency
radiated field
10V/m prior to modulation
80 - 1000MHz
80% AM (1kHz) modulation
(reduce to 3V/m for 87-108MHz)
Module enclosure Level 3
(industrial)
ENV 50141* Conducted radio
frequency
10V prior to modulation
0.15 - 80MHz
80% AM (1kHz) modulation
Control and
power lines
Level 3
(industrial)
EN 61000-4-4* Fast transient burst 5/50ns 2kV transient at 5kHz repetition
frequency via coupling clamp
Control lines Level 4
(industrial harsh)
5/50ns 2kV transient at 5kHz repetition
frequency by direct injection
Power lines Level 3
(industrial)
EN50082-1 Generic immunity standard for the residential, commercial and light -
industrial environment
Complies
EN50082-2 Generic immunity standard for the industrial environment
Calls up basic standards marked *
Complies
EN61800-3
IEC61800-3
Product standard for adjustable speed power Drive systems
(immunity requirements)
Meets immunity requirements for first
and second environment
