Control Techniques Mentor II User Manual

18 Mentor ll User Guide
www.controltechniques.com Issue Number: 12
6.5 Terminals index
Terminals are located on PCB MDA2B, Figure 6-1 and Figure 6-4
PL5
Terminal
Description Type Programmable
Block Number
TB1 1 +10V Reference supply
2 -10V Reference supply
3 Speed reference Analog input Yes
4, 5, 6, 7 General purpose GP1, GP2, GP3, GP4 Analog inputs Yes
8 Motor thermistor (thermal) Analog input
9 Tachogenerator (tachometer) negative Analog input
10 Tachogenerator (tachometer) positive (0V) Analog input
TB2 11 Current Analog output
12 DAC1 Analog output Yes
13 DAC2 Analog output Yes
14 DAC3 Analog output Yes
15, 16, 17, 18, 19 ST1, 2, 3, 4, 5 Open collector outputs Yes
20 0V
TB3 21 F1 Run permit Digital input
22 F2 Inch reverse Digital input Yes
23 F3 Inch forward Digital input Yes
24 F4 RUN reverse (latched) Digital input Yes
25 F5 RUN forward (latched) Digital input Yes
26, 27, 28, 29, 30 F6, 7, 8, 9, 10 Digital inputs Yes
TB4 31 ENABLE Digital input
32 RESET Digital input
33 +24V relay supply
34 Pole Relay output (ST6) Yes
35 Normally closed contact Relay output (ST6) Yes
36 Normally open contact Relay output (ST6) Yes
37 Pole Drive ready relay
38 Normally closed contact Drive ready relay
39 Normally open contact Drive ready relay
40 0V
Number Function Number Function Number Function
1 +10V 11 Current 21 F1
2-10V 12DAC1 22 F2
3 Speed ref 13 DAC2 23 F3
4 GP1 14 DAC3 24 F4
5GP2 15ST1 25 F5
6GP3 16ST2 26 F6
7GP4 17ST3 27 F7
8 Thermistor (thermal switch) 18 ST4 28 F8
9 NC 19 ST5 29 F9
10 0V 20 0V 30 F10
31 ENABLE
32 RESET
33 External 24V
34 0V
