Control Techniques Mentor II User Manual

Mentor ll User Guide 15
Issue Number: 12 www.controltechniques.com
Figure 6-3 Four quadrant power connections
M
T
MT
B
R Y
B
LF LC
LR
LC
L1
L2
L3
E1 E2 E3
1320
MBS
Motor
blower
+10V 0V
31 25 21A1
A2 F1 F2
910
840
0V
0V
L11
L12
39
37
RL1
RR LC
RR
MBS
LC
RR
START
STOP
Drive Ready
LK
LC
RR
Manual
set
speed
Four Quadrant
RL2
Zero Speed
35
34
LC
Fuses for wiring protection only
Only need to connect E2 with North American field bridge and for field supply on M350(R) to M1850(R)
LR Line reactors LC Line contactor LF Line fuses LK Link (Jumper) MBS Motor blower starter MT Motor thermal switch RR Run relay T Tachogenerator
(Tachometer)
Terminals 31 Enable 21 Run permit 25 Run forward
Function
Ground
