Control Techniques Mentor II User Manual

74 Mentor ll User Guide
www.controltechniques.com Issue Number: 12
0 = use last values
1 = use updated values
The two Precision Reference values, 13.06 and 13.07, cannot be
changed simultaneously. To prevent the Position Loop reading
inconsistent values during the change, parameter 13.13 =0(default)
enables the Position Loop to continue to use the last values while the
change is taking place. When a change of both 13.06 and 13.07 has
been completed, setting 13.13 = 0 causes the updated values to be
applied. 13.13 should then be reset to 0, ready for the next update.
This parameter is a wide integer equivalent to the Precision Reference
13.06 and 13.07, and allows the precision reference to be written as a
single statement, removing the need for the latch, parameter 13.13.
Parameter 13.14 is intended primarily for use through serial
communications.
13.13 Precision reference latch
RW Bit
ô
0or1
ð
0
13.14 Precision speed reference (16-bit)
RW Uni
ô
000 ~ 65535
ð
0
