Special Parameters in Menu 15
This parameter is the equivalent of parameters 15.16 and 15.17,such
that Ratio 1 in the Digital Lock software can be written simultaneously,
removingtheneedforthelatch,15.31.
This parameter is the equivalent of parameters 15.18 and 15.19,such
that Ratio 2 in the Digital Lock software can be written simultaneously,
removingtheneedforthelatch,15.31.
When serial (interface) Mode 4 is selected, this parameter is loaded with
a variable input from the serial (interface) port.
Refer also to parameter 11.13.
When serial (interface) Mode 4 is selected, this parameter is transmitted
to the next Drive down the line.
Special Parameters in Menu 16
This parameter indicates the state of the CTNet network.
A value greater than 0 indicates a healthy network, with the value
representing the number of messages per second received by the node.
A value of 0 indicates a healthy network, but no data is being
transmitted. This usually indicates that there is no node configured to
generate cyclic synchronisation messages.
A value of -1 indicates an unhealthy network caused by cabling error, no
terminationresistors,noothernodesonnetwork,etc.
A value of -2 indicates initialisation failure, such as baud rate mismatch
or illegal address. Often this will be accompanied with a trip on power-
up.
This parameter is only used when the DPL program has been compiled
with the debugging information switched on. The value it gives indicates
the approximate line number within the DPL program where a run-time
error occurred. If no run-time error has occurred, the value will be
meaningless.
15.60 Ratio 1 wide integer
RW Uni
ô
0 ~ 65535
ð
000
15.61 Ratio 2 wide integer
RW Uni
ô
0 ~ 65535
ð
000
15.62 Serial Mode 4 input data
RO
ô
0 ~ 65535
ð
15.63 Serial Mode 4 output data
RO
ô
0 ~ 65535
ð
16.62 CTNet diagnostic parameter
RO
ô ð
16.63 DPL line number where trip occurred
RO
ô ð
