Control Techniques Mentor II User Manual

86 Mentor ll User Guide
www.controltechniques.com Issue Number: 12
1H
1G
1F
60 to 300V
50 to 200V 10 to 50V
RV1
Switches
SW1F,G,H,
refer to Fig 14
9
10
T
Tachogenerator
(Tachometer) Input
Thermistor
(Thermal switch)
Input
Motor temp.
20
8
Disable o/temp. trip
10.21
10.32
0 1
3300
Ω
Ω Ω
Ω
1800
Ω
Ω Ω
Ω
TRIP
Menu 07 ANALOG INPUTS & OUTPUTS
Current Loop / Encoder (Pulse Tach.) Inputs
Encoder scaling
Current loop
mode select
Current
loop
select
V
TB1 - 03
Voltage-
to-frequ.
convertor
Encoder
ref. select
PL4
Speed ref.
destination
Speed ref.
Input
Speed ref.
scaling
07.15
07.05 07.20
07.27 07.28
07.25
07.26
07.24
0 1
1 0
CURRENT LOOP
INPUT SELECTION
Input
07.28 07.27
0-20mA 0 0 20-0mA 0 1 4-20mA 1 0 20-4mA 1 1
NOTE
GP2 becomes dedicated
as Mains Healthy
(AC Power Normal)
input
when parameter 11.24 = 1
Scaling
Scaling
Analogue Inputs
Scaling
07.11
07.01 07.16
07.13
07.03
07.18
07.14
07.04 07.19
07.12
07.02 07.17
Scaling
GP - 1 GP - 2 GP - 3 GP - 4
4 5 6 7
20
0to±10V 0to±10V 0to±10V 0to±10V
Hard speed ref.
Default 03.18
Speed ref. 3
Default 01.19
Speed ref. 4
Default 01.20
Torque ref.
Default 04.08
Scaling
Scaling
Armature voltage Default 03.04
Actual speed
Default 03.02
Final speed
demand
Default 02.01
Analogue
Outputs
Scaling
07.08
07.21
07.09
07.22
07.10
07.23
DAC-1 DAC-2 DAC-3
11 12 13 14
20
0to+6.6V corresp. To 0to150%I
0to±10V 0to±10V 0to±10V
I
motor
Max loading 5mA
Invisible parameters
are in italics,
eg 07.11
KEY
R/W
logic
R/O
logic
Internal
logic
Input impedance 100k
Ω
Ω Ω
Ω
