BS Controller for AC SERVO PRESS
Instruction Manual Ver1.08
BS-M3A-1B
- 47 -
PB33
VRF1B
Gain changing vibration
suppression control vibration
frequency
setting
100.0
Hz
0.1-100.0
PB34
VRF2B
Gain changing vibration
suppression control resonance
frequency
setting
100.0
Hz
0.1-100.0
PB35
VRF3B
For manufacturer setting
0.00
0.00-1.00
PB36
VRF4B
For manufacturer setting
0.00
0.00-1.00
PB37
VP1
For manufacturer setting
100
pulse
0-32767
PB38
TGW1
For manufacturer setting
0.0
0.0-20.0
PB39
TGW2
For manufacturer setting
0.0
0.0-20.0
PB40
TGW3
For manufacturer setting
0.0
0.0-20.0
PB41
VRFF1
For manufacturer setting
1125
Hz
1-1125
PB42
VRFF2
For manufacturer setting
1125
Hz
1-1125
PB43
VRFQ
For manufacturer setting
0004
0000-0304h
PB44
For manufacturer setting
0000
0000-FFFFh
PB45
For manufacturer setting
0000
0000-FFFFh
Parameter C
No.
Symbol
Name
Setting
Unit
Range
Change
required
PC01
STA
Acceleration time constant
0
ms
0-50000
PC02
STB
Deceleration time constant
0
ms
0-50000
PC03
STC
S-pattern acceleration/deceleration
time constant
0
ms
0-1000
PC04
TQC
Torque command time constant
500
ms
0-20000
PC05
SC1
Internal speed command 1
100
r/min
0-50000
PC06
SC2
Internal speed command 2
500
r/min
0-50000
PC07
SC3
Internal speed command 3
1000
r/min
0-50000
PC08
SC4
Internal speed command 4
200
r/min
0-50000
PC09
SC5
Internal speed command 5
300
r/min
0-50000
PC10
SC6
Internal speed command 6
500
r/min
0-50000
PC11
SC7
Internal speed command 7
800
r/min
0-50000
PC12
VCM
Analog speed command maximum
speed
0
r/min
0-50000
PC13
TLC
Analog torque command maximum
output
100.0
%
0.0-1000.0
PC14
MOD1
Analog monitor output 1
0000
0000-041Fh
PC15
MOD2
Analog monitor output 2
0001
0000-041Fh
PC16
MBR
Electromagnetic brake sequence
output
100
ms
0-1000
PC17
ZSP
Zero speed
50
r/min
0-10000
PC18
*BPS
Alarm history clear
0000
0000-0001h
PC19
*ENRS
Encoder output pulses selection
0000
0000-0021h
PC20
*SND
Station number setting
0
station
0-31
PC21
*SOP
Communication function selection
0040
0000-0150h
*
PC22
*COP1
Function selection C-1
0000
0000-1111h
PC23
*COP2
Function selection C-2
0000
0000-1511h
PC24
*COP3
Function selection C-3
0000
0000-0061h
