14
2.3 Battery Cabinet Design
2.3.1 Battery Cabinet Appearance
FRONT VIEW
The front of the container is equipped with two
doors and indicator lights. Its external grounding
point is located on the front of the container.
SIDE VIEW
Removable side plates are provided on
the sides of the cabinet.
TOP VIEW
There are four lifting rings on top of the cabinet enclosure.
