2.11 Parallel Operation
The cabinet dimensions for the CPS ES-125 kW and CPS ES-250 kW models are the same; two 125 kW modules can operate
in parallel. The AC output of the two modules have their own built-in 200 A circuit breaker and the outputs are combined, thus
only one set of AC busbars (L1/L2/L3) is shown. Each 125 kW module pairs with a single 279.55 kWh battery cabinet.
