3 Shipping and Delivery
3.1 Shipping Requirements
The internal components of the PCS and battery cabinets listed in this manual are pre-installed prior to shipment. The
following two lifting methods can be used:
1. Use a crane to lift and transport the PCS and battery cabinets.
2. Use a forklift to lift and transport the battery cabinets.
WARNING:
 During transportation, loading, and unloading of the ESS, the local safety regulations MUST be followed.
 All lifting and transportation equipment MUST be properly maintained.
 The loading, unloading, and bolting of the products must be performed ONLY by qualified personnel.
3.1.2 Product Package Weight and Dimensions
Product
Product Dimensions
(L × W × H)
Package Dimensions
(L × W × H)
Gross Weight
279.55 kWh battery cabinet
51.2 × 51.2 × 92.1 in
(1300 × 1300 × 2340 mm)
54.7 × 54.7 × 96.6 in
(1390 × 1390 × 2454 mm)
Approximately
6757.2 lb (3065 kg)
125 kW PCS cabinet
29.8 × 52.4 × 89.8 in
(757 × 1330 × 2280 mm)
39.4 × 55.9 × 97.3 in
(1000 × 1420 × 2471 mm)
Approximately
1653 lb (750 kg)
250 kW PCS cabinet
29.8 × 52.4 × 89.8 in
(757 × 1330 × 2280 mm)
39.4 × 55.9 × 97.3 in
(1000 × 1420 × 2471 mm)
Approximately
1874 lb (850 kg)
