CPS ES Series - Battery Cabinet Dimensions

15
2.3.2 Battery Cabinet Dimensions
The dimensions of the battery cabinet are shown below.
Figure 2-3 Battery Cabinet Dimensions
Width Depth Height
Weight
51.2 in
(1300 mm)
51.2 in
(1300 mm)
92.1 in
(2340 mm)
6613 lb ± 110 lb
(3000 kg ± 50 kg)
including internal equipment
