5.3 Cabinet Door Closing Procedure
5.3.1 Closing the Battery Cabinet Door
1. Turn the door lock handle to its highest point (see Figure 5-4).
NOTE: Avoid scratching the lock body with the handle during this process to avoid removing the paint.
Figure 5-2
2. Close the door using the following steps:
a. Press down on the upper part of the small door lock ①.
b. Press your thigh and knee against the small door ②.
c. While performing steps 2.a and 2.b simultaneously, use your hand to turn the handle downward ③.
Figure 5-3
