No. Item Specification Note
5
Electrical
performance
Charging
current
Rated 140 A -
Maximum 160 A (lasts 1 min) -
6
Discharging
current
Rated 140 A -
Maximum 160 A (lasts 1 min) -
7
Nominal power 279.55 kWh -
8
Voltage range 873.6-1123.2 V
DC
2.8-3.6 V
9
Nominal voltage 998.4 V
DC
3.2 V
10
Max. continuous current 160 A -
11
Rated power 139.7 kW Mapping
12
Auxiliary power 176-264 V AC (L-N) 50 / 60 Hz
13
General
cabinet
specifications
Dimensions
(H × W × D)
89.8 × 51.2 × 51.2 in
(2280 × 1300 × 1300 mm)
Including lifting holes
14
Color RAL7035 -
15
Weight
6613.9 ±110.2 kg)
(3000 ±50 kg)
-
16
Anti-corrosion grade C5 ISO 12944-2
17
Earthquake resistance rating Magnitude 9 earthquake
2016 California
building code SDC D
18
Seal class NEMA 3R IP66
19
Power connection Fast plug -
20
Grounding mode
System grounding resistance ≤ 4 Ω
(meets local requirements)
-
21
Communication mode Modbus TCP -
