CPS ES Series - Page 30

30
Table 2-4 Battery Thermal Management Specifications
No. Specification Parameters / Requirements
1
Ambient temperature
0-13123.4 ft (0-4000 m);
refrigerating capacity derates ≤ 3% per 3280.8 ft (1 km).
Relative humidity 0-95%
Coastal / seaside environment requires C5 anti-corrosion level
2
Cooling power
Rated value 3 kW @ 113°F (45°C) ambient temperature /
coolant effluent temperature 64°F (18°C)
3
Heating power Rated value 3 kW @ -22°F (-30°C) ambient temperature
4
System energy efficiency ratio
Internal parts of the system need heat preservation:
COP > 1.6 @ 113°F (45°C), 2.6 @ 95°F (35°C)
5
Power requirements 176-264 V single phase power supply, 60 / 50 Hz, L / N / PE
6
Communication function requirements CAN communication function with BMS, baud rate 500 kbps
7
Weight <370.4 lb (<160 kg)
8
Dimensions (H × D × W)
41.3 × 45.3 × 10.8 in
(1050 × 1150 × 275 mm)
9
Color RAL 7035
