Equipment Specifications
Dimensions (W × H × D)
PCS cabinet: 29.8 × 89.8 × 52.4 in (757 × 2280 × 1330 mm)
Battery cabinet: 51.2 × 92.1 × 51.2 in (1300 × 2340 × 100 mm)
Weight
125 / 250 kW PCS cabinet: 0.73 T / 1455 lb (662.2 kg)
279.55 kWh Battery cabinet: 3.0 T / 6613.9 lb (2721.6 kg)
Handling method Forklift pockets and lifting lugs
Fire suppression NFPA 68 compliant aerosol
Operating temperature range -13°F to 131°F / -25°C to 55°C
Storage temperature range -31°F to 140°F / -35°C to 60°C
Operating altitude ≤ 6561.7 ft / 2000 m
Operating humidity 0-95% (non-condensing)
System monitoring Ethernet / RS485
Key System Components
Bi-directional energy storage inverter Yes
High-voltage lithium-ion battery Yes
DC disconnect (load rated) Yes
AC disconnect (load rated) Yes
Climate control system Yes
Warranty
Standard 3 years
Extended terms 5 and 10 years
