MEMORY (1) SD memory card slot;
Accepts one SDor SDHCcard up to 32GB for storage of log files
IR/SERIAL1–4 (1) 8-pin 3.5mm detachable terminal block;
Comprises (4) IR output ports;
IR output up to 1.2MHz;
1-way serial TTL/RS-232 (0–5V) up to 115.2k baud;
IRP2 IR emitters sold separately
RELAYS1–4 (1) 8-pin 3.5mm detachable terminal block;
Comprises (4) normally open, isolated relays;
Rated 1A, 30VAC/VDC;
MOV arc suppression across contacts
COMPUTER (1)USBType-B connector, female;
USB2.0 computer console port;
For setup only
PWR (1) 2-pin 3.5mm detachable terminal block;
24VDC power input for power pack (sold separately)
NET (2) 4-pin 3.5mm detachable terminal blocks, paralleled;
Cresnet master port
USB (1) USB Type-A connector, female;
USB 2.0 port for storage devices
LAN PoE (1) 8-pin RJ-45 connector, female;
100BASE-T Ethernet port;
PoE (Power over Ethernet) PD (Powered Device) port
Controls and Indicators
PWR (1) Bicolor green/amber LED, indicates operating power is present;
Amber indicates that the device is booting and is not yet ready to operate;
Green indicates that the device is ready to operate
NET (1) Amber LED, indicates communication with Cresnet devices
MSG (1) Red LED, indicates control processor has generated a logging message
HW-R (1) Recessed miniature push button, initiates a hardware reset
SW-R (1) Recessed miniature push button, initiates a software reset
LAN (1) Bicolor green/amber and (1) amber LEDs;
Green/amber LEDindicates Ethernet link status and connection speed;
Amber LEDindicates Ethernet activity
Power
Power Source Options Power pack (sold separately)or Power over Ethernet (PoE)
Power Pack Must supply 24VDCto 2-pin terminal block via flying leads;
Use model PW-2407WULor equivalent
Power over Ethernet
(PoE)
IEEE 802.3at Type 1 (802.3af compatible) Class 0 (12.95W) PoE Powered
Device
Available Cresnet Power 2.5W maximum via PoE;
10 W maximum via 0.75@24VDC power pack
Power Consumption 9.7W (not including any connected Cresnet devices)
