54 • 4-Series™ Control Systems Product Manual — Doc. 8559B
Environmental
Temperature 41 to 113°F (5 to 45°C)
Humidity 10% to 90% RH (noncondensing)
Heat Dissipation 33BTU/hr
Enclosure
Housing Light gray polycarbonate housing with polycarbonate label overlay, UL94 V-0
rated
Mounting 35mm DIN EN 60715 rail mount;
DIN 43880 form factor for enclosures with 45mm front panel cutout;
Occupies 9 DIN module spaces (162mm)
Dimensions
Height 3.57in. (91mm)
Width 6.33in. (161mm)
Depth 2.28in. (58mm)
Weight
1.1lb (0.50kg)
Compliance
Regulatory Model: DIN-AP4;
UL® Listed for US & Canada, CE, IC, FCC Part 15 Class B digital device
To search for product certificates, refer to support.crestron.com/app/certificates.
