Page 30
WIRELESS PROGRAMMINGWIRELESS PROGRAMMING
Wireless Detector Learning
To learn a Wireless Detector as a zone input on the panel, press the appropriate address number (eg
604 for Zone 4). The keypad buzzer will beep once a second to indicate learn mode has been initiated
and the Led on the RX-40 board will flash. The Wireless detector you wish to load must transmit a signal
within 30 seconds of entering learn mode otherwise the panel will time out and no code will be loaded. If
a valid code is received within the 30 seconds the keypad will give 3 short beeps and exit learn mode.
To remove a loaded Wireless Detector at a single address only, enter in the address you wish to delete
the code at eg 604, then without operating the transmitter and before the 30 second timer expires press
the “Enter” button.
601 Learn Mode for Zone 1
602 Learn Mode for Zone 2
603 Learn Mode for Zone 3
604 Learn Mode for Zone 4
605 Learn Mode for Zone 5
606 Learn Mode for Zone 6
607 Learn Mode for Zone 7
608 Learn Mode for Zone 8
Wireless Detector Zone Options Default= 0
This block of addresses (231 - 238) are used to select the type of detector to be used on the Wireless zone input
and allow functions such as battery low, tamper and normal alarm to be correctly recognized. To make the Wireless
zone work you must also tell the zone input that it is a Wireless zone (Address 134 zones 1-8).
231 Zone 1 Options 0 For Unknown Devices - No Low Battery, No Tamper reporting
1 Crow AE Wireless PIR / Smoke Detector with Battery Low reporting
2 Crow AE Wireless Reed Switch with Door Open / Close & Low Batt Status Reporting
3 Crow Merlin Wireless PIR (supervised signal Disabled (Ignored))
4 Crow Merlin Wireless PIR (supervised signal Enabled (Active))
5 Crow Freelink Wireless with checksum (supervision signal Disabled (Ignored))
6 Crow Freelink Wireless with checksum (supervision signal Enabled (Active))
11 Ness Wireless devices Battery Low
12 Ness Wireless Reed Switch
21 Electronics Line ‘Cougar’ Wireless PIR (“ON” = Switch 1, “OFF” = Switch 2, 3 & 4)
31 Visonic K900 Wireless PIR
32 Visonic Powercode Devices (supervised signal ignored)
33 Visonic Powercode Devices (supervised signal active)
1 Crow AE Wireless Series with Battery Low - If a Crow (AE) Wireless pendant / PIR / Smoke is used
on the PowerWave Wireless receiver, setting this bit allows the panel to correctly recognize the battery
low signal from Crow devices.
2 Crow AE Wireless Series Radio Reed Switch - If a Crow (AE) Wireless Reed Switch is used on the
PowerWave Wireless receiver, setting this bit allows the panel to correctly recognize the battery low
signal from this Crow device. This bit also recognizes the Open and Closed signals from the reed switch
so the zone LED can follow the correct state of the reed switch (i.e. Door Open or Closed). If No Door
Open / Close status reporting is required, then the AE Reed Switch HAS to be assigned as a type
“ 1 ” (AE PIR) and the “Restore” transmissions disabled by removing one of the internal jumpers within
the AE reed switch unit.
3 Crow Merlin PIR (unsupervised) - If a Crow Merlin wireless PIR is used on the PowerWave Wireless
receiver, setting this bit allows the panel to correctly recognize the alarm, tamper & battery low signal
from the device. The automatic supervised signal sent every 40 minutes by the PIR is ignored in this
mode.
4 Crow Merlin PIR (supervised) - If a Crow Merlin Wireless PIR is used on the PowerWave wireless
receiver, setting this bit allows the panel to correctly recognize the alarm, tamper & battery low signal
from the device. Setting this option on also starts a 4 hour timer for the supervised signal. The 4 hour
timer is constantly being reset while valid supervised signals are being received every 40 minutes. If no
supervised signals are received from the PIR within the 4 hour period, a supervised alarm is generated.
