DAELIM S2 250

17-4
IGNITION SYSTEM
A.C. GENERATOR INSPECTION
EXCITER/PUISE COIL INSPECTION
● Remove the luggage box.
● Disconnect the A.C. generator connector.
● Measure the exciter coil resistance between the
black/white wire terminal and ground.
IGNITION UNIT
INSPECTION
● Measure the resistance between terminals.
● Disconnect the pulser coil wire coupler.
● Measure the pulser coil resistance between the
blue/white and green/white wire terminals.
·Black/white~Ground 23~35
㏀
(+)
(-)
L/Y
B/Y
G/GR
G/W
B/W
G/B
V/R
V/B
V/G
G
11~22M
67~125 K
11~22 M
36~67 K
110~200 K
36~67 K
36 ~ 67 K
0.5~2 K
67~125 K
11~22M
11~22M
36~67 K
110~200K
36~67K
36~67K
36~67 K
11~22M
36~67 K
11~22M
72~133K
2~5K
2~5K
110~200 K
11~22M
110~200 K
11~22M
72~133K
72~133K
72~133K
36~67 K
11~22M
36~67 K
11~22M
2~5K
72~133K
0.1~1
36~67 K
11~22M
36~67 K
11~22M
2~5K
72~133K
0.1~1
Unit : Ω
0.5~2K
L/Y B/Y G/R G/W B/W G/B V/R V/B V/G G
V/R V/B V/G
B/W G/B G
G/W B/Y
L/Y G/GR
·Black/white~Green/white 50~170 ㏀
