18-1
18. STARTER SYSTEM
SERVICE INFORMATION
GENERAL SAFETY
● The starter motor can be maintained without removing the engine from the vehicle.
● A weak battery may be unable to turn the starter motor quickly enough, or, supply adequate ignition current.
● The starter motor may be damaged if current is allowed to flow to it when the engine cannot turn over.
● The engine may not be turned over if the stop switch is faulty.
SPECIFICATION
18
SERVICE INFORMATION
········
18-1
TROUBLESHOOTING
··········
18-2
STARTER MOTOR
············
18-3
STARTER MAGNETIC SWITCH
··
18-5
ITEM
STARTER MOTOR BRUSH LENGTH
STANDARD VALUE
12.5 mm
SERVICE LIMIT
5 mm
TORQUE
STARTER MOTOR MOUNTING BOLT : 0.67~1.08kgf·m
STARTER MOTOR CASE SCREW : 0.29~0.49kgf·m
STARTER CLUTCH BOLT : 0.98~1.37kgf·m
·Always turn the ignition switch OFF before servicing the starter motor. The moter could suddenly start, causing
serious injury.
