DAELIM S2 250 Service Manual

8-12
LH. CRANKCASE COVER/CONTINUOUSLY VARIABLE TRANSMISSION
●Install the clutch/driven pulley onto the drive shaft.
● Install the clutch outer.
● Hold the clutch outer with the universal holder.
● Install and tighten the clutch outer nut.
TORQUE VALUE : 4.9~5.88kgf
·
m
● Install the drive belt.
● Install the LH. crankcase cover.
CLUTCH OUTER
FLANGE NUT
UNIVERSAL HOLDER
