95XF series Inspection and adjustment
EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
3-9
1. Disconnect the battery earth lead.
2. Remove the valve covers. See “Removal
and installation”.
3. If the v ehicle is equipped with a C-brake,
the C-brake must be removed first, see
chapter “Removal and installation”.
4. Tighten the rocker s haft attachment bolts to
the s pecified torque. See “Technical data”.
M2143
5. Tighten the rocker-housing attachment
bolts, in the order shown in the diagram, to
the s pecified torque. See “Technical data”.
M2144
4 25
316
7 8
6. Tighten the attachment bolts of the unit
injectors to the specified torque, see
“Technical data”.
M2145
5
200424
