DAF 95XF - Page 84

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
Inspection and adjustment 95XF series
3-24
Bleeding the XF engine fuel system
While bleeding the fuel system, fuel
will escape. Collect this fuel,
bearing in mind the risk of fire.
1. Open the bleed screw (1) on the filter
housing.
2. Using the hand pump (2), pump fuel
through the system until fuel without air
bubbles flows through the bleed screw.
3. Close the bleed screw (1).
i 400172
1
2
Bleeding the XE engine fuel system
While bleeding the fuel system, fuel
will escape. Collect this fuel,
bearing in mind the risk of fire.
Dirt in the fuel system can lead to
significant damage to pump units
and housing.
1. Open the bleed screw (1) on the filter
housing.
2. Using the hand pump (2), pump fuel
through the system until fuel without air
bubbles flows through the bleed screw.
3. Close the bleed screw (1).
i 400252
1
2
5
 200424
