95XF series Inspection and adjustment
EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
3-25
3.16 CHECKING THE GLOW COILS
Note:
To avoid engine damage it is important that the
glow coils be checked periodically.
1. Check the glow coils for the following
points:
- windings that have worn thin due to
abrasion (A);
- coil end broken or worn thin due to
continuous knocking of a loose
insulator (B);
- broken coil windings (C).
2. Replace all glow plugs if one or more of the
above-mentioned situations occur.
BA
C
B
A
M200818
;;
;;
