User's Manual
106
Step 8 Click Save.
6.4.3 Configuring In Area No.
The system counts the number of people in and out of the detection area. When the number of
entry or exit is larger or smaller than the threshold or when the dwell time of any person in the area
is greater than the threshold, an alarm is triggered.
Step 1 Click , click , and then select
EVENT.
Step 2 Select a camera in the device tree, and then select AI Application > People Counting >
People Counting.
Step 3 Click Add Rule, select In Area No., and then click to enable the function.
Step 4 Draw a detection area.
●
Click to draw the detection area.
●
Click to set the whole image as the detection area.
Figure 6-66 In Area No.
Step 5 Set parameters.
Table 6-13 Parameter description of In Area No.
Area People
Counting Alarm
1. Click to enable the alarm.
2. Set people number threshold.
●
If you select and then enter a number, alarm is triggered
when the detected number is larger or equal to the number that
you entered.
●
If you select and then enter a number, alarm is triggered
when the detected number is smaller or equal to the number that
you entered.
Strand Alarm
1. Click to enable the alarm.
2. Set time threshold for the alarm. When the dwell time of any person
in the area is greater than the threshold, an alarm will be triggered.
