Figure 8-15 Geographical position
4. Drag the text box to the proper position.
5. Click to save the OSD information.
●
Set privacy masking
This function is available only when the camera supports privacy masking.
1. Click to enable privacy masking.
2. Click
Add, select the masking type and color, and then draw mosaic or color blocks
in the image as needed.
3. Drag blocks to the proper position.
4. Click to save the OSD information.
Step 4 Click
Save.
8.2.2.3.5 Configuring Audio Parameters
Step 1 Click , or click on the configuration page, and then select DEVICE.
Step 2 Select a remote device on the left panel and then click Audio tab.
Figure 8-16 Audio
Step 3 Select an audio output type.
●
LineIn: The Device acquires audio signals through external audio device.
●
Mic: The Device acquires audio signals through internal mic.
Step 4 Click to enable Noise Filter.
Step 5 Click the Main Stream, Substream1 or Substream2 tab, and then configure the
parameters.
