User's Manual
107
Max Detect Height 0–300.
Min Detect Height 0–300.
Step 6 Select a schedule in the Deployment Time drop-down list.
Alarms are triggered only within the scheduled time.
Step 7 Click Actions to set alarm linkage actions.
Step 8 Click Save.
6.4.4 Configuring Queuing Detection
The system counts the number of people queuing in the detection area. When the number of people
exceeds the threshold or the queue time is longer than the pre-defined time, an alarm is triggered.
Step 1 Click , click , and then select
EVENT.
Step 2 Select a camera in the device tree, and then select AI Application > People Counting >
Queuing.
Step 3 Draw a queuing detection area.
1) Click to draw the first detection area.
Click to draw more areas. You can draw 4 areas at most.
2) Click to edit the area.
Figure 6-67 Queuing
Step 4 Set parameters.
Table 6-14 Parameter description of queuing detection
Enable Click to enable the selected area.
Name Enter the area name.
