Dahua DH-XVR1B08 User Manual

Local Configurations 84
Function
Description
Auto Focus
Point to the channel window and right-click on it to open the
shortcut menu, and then click Auto Focus.
Not all cameras support this function.
Color Setting
Open the COLOR interface where you can adjust the video image
color.
Click to modify the camera properties.
Sub Port
Click to switch to extra screen control.
Table 5-14
5.2.5 Color Setting
You can adjust the video image color effect such as sharpness, brightness, and contrast. The
parameters are different according to the connected camera type. Take analog channel as an
example.
In the live view screen, right-click on the analog channel to see the shortcut menu, and then
select Color Setting, the COLOR interface is displayed. See Figure 5-43.
For details, see "5.5.1 Configuring Image Settings."
Figure 5-43
Parameter
Description
Period
Divide 24 hours into two periods and configure the corresponding
color settings.
Effective Time
Enable the function and then set the effective time for each period.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
