Dahua DH-XVR1B08 User Manual

Local Configurations 150
5.9.8 Using the File List
You can view all the recorded videos within a certain period from any channel in the File List.
Select Main Menu > VIDEO, the video search interface is displayed. Step 1
Select a channel(s). Step 2
Click . Step 3
The File List interface is displayed. See Figure 5-114.
Figure 5-114
Start playback. Step 4
 Click , the playback starts from the first file by default.
 Click any file, the system plays back this file.
 In the time box on the top of the file list interface, you can enter the specific time to
search the file that you want to view.
 In the File List area, there are 128 files can be displayed.
 File type: R indicates general recorded video; A indicates recorded video with
external alarms; M indicates recorded video with motion detection events; I
indicates recorded video with intelligent vents.
 Click to return to the interface with calendar and CAM NAME list.
Locking and Unlocking the Recorded Video

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
