Dahua DH-XVR1B08 User Manual

The Grand Tour 14
3.1.6 DH-XVR7208A-4KL-X/DH-XVR7216A-4KL-X/DH-XVR7208A-
4K-X
Figure 3-6
No.
Port Name
Function
1
Status indicator light
Glows blue when the device is working properly.
2
USB port
Connects to the external devices such as keyboard, mouse,
and USB storage device.
Table 3-6
3.1.7 DH-XVR7416L-4KL-X
Figure 3-7
No.
Port Name
Function
1
IR receiver
Receives infrared signal from remote control.
2
USB port
Connects to peripheral devices such as USB storage
device, keyboard, and mouse.
Table 3-7
3.1.8 DH-XVR7816S-4KL-X/DH-XVR7816S-4KL-X-LP
Figure 3-8

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
