Dahua DH-XVR1B08 User Manual

Local Configurations 139
Figure 5-102
Configure the settings for the record control parameters. See Table 5-32. Step 2
Parameter
Description
Channel
Displays all the analog channels and the connected digital channels.
You can select a single channel or select All.
Record status
Auto: Automatically record according to the record type and

recording time as configured in the recording schedule.
Manual: Keep general recording for 24 hours for the selected

channel.
Stop: Do not record.

Snapshot status
Enable or disable the scheduled snapshot for the corresponding
channels.
Table 5-32
5.9.2 Instant Playback
You can use the instant playback function to play back the previous five minutes to sixty
minutes of the recorded video in any channel. For details about instant playback function, see
"5.2.2.1 Instant Playback."
5.9.3 Main Interface of Video Playback
You can search for and play back the recorded video saved on the Device.
Select Main Menu > VIDEO, the video search interface is displayed. See Figure 5-103.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
