Dahua DH-XVR1B08 User Manual

Local Configurations 104
Figure 5-64
5.4.5 Calling OSD Menu
For the coaxial camera, you can call the OSD menu through the Expanded PTZ Control Panel.
See Figure 5-63.
On the Expanded PTZ Control Panel, click . Step 1
The MENU OPERATION interface is displayed. See Figure 5-65.
Figure 5-65
Click Enter. Step 2
The OSD menu is displayed. See Figure 5-66.
Figure 5-66
On the MENU OPERATION interface, click the arrow button to select the onscreen Step 3
parameters.
Click Enter to complete the settings. Step 4

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
