Dahua DH-XVR1B08 User Manual

Local Configurations 138
Figure 5-101
Enable the FTP function and configure the parameters. For details, see "5.18.9 Step 2
Configuring FTP Storage Settings."
The snapshots will be uploaded to FTP for backup.
5.9 Playing Back Video
5.9.1 Enabling Record Control
 Manual recording operation requires the user have the permission to access STORAGE
settings.
 Check to ensure the HDD installed in the Device has been formatted properly.
To enter the record control interface, do the following:
Right-click on the live view screen, the shortcut menu is displayed. On the shortcut Step 1
menu, select Manual > Record Control. The RECORD interface is displayed, see
Figure 5-102.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
