Dahua DH-XVR1B08 User Manual

Local Configurations 268
If the importing is successful, the audio files will display in the FILE MANAGER
interface. See Figure 5-235.
Figure 5-235
The imported audio files are automatically saved into the HDD, so you do not need to
connect to the USB storage device to get the file next time.
 Click to play the audio file.
 Click to rename the audio file.
 Click to delete the audio file.
 To decrease or increase the playing volume, move the slider to the left or to the
right.
5.17.2 Configuring Playing Schedule for Audio Files
You can configure the settings to play the audio files during the defined time period.
Select Main Menu > AUDIO > SCHEDULE. Step 1
The SCHEDULE interface is displayed. See Figure 5-236.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
