Dahua DH-XVR1B08 User Manual

Local Configurations 207
The video playback interface is displayed. See Figure 5-170.
Figure 5-170
Click to play back the recorded video. Step 8
Click Back to stop the playback and return to the SMART SEARCH interface.
Step 9
Click Export to export the recorded video files.
5.12 IoT Function
5.12.1 Configuring Sensor Settings
You can connect external sensors wirelessly through the Device with USB gateway or through
connecting to a camera gateway. After connection, you can activate alarm events through
external sensors.
5.12.1.1 Connecting Sensor through Device
Only the Device with USB gateway supports this function.
Select Main Menu > IoT > MANAGER > Sensor Pairing. Step 1
The Sensor Pairing interface is displayed. See Figure 5-171.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
