Dahua DH-XVR1B08 User Manual

Local Configurations 116
Figure 5-75
Click Browse. Step 2
The Browse interface is displayed.
Select the upgrade file and then click OK.
Step 3
The COAXIAL UPGRADE interface is displayed.
You need to insert the USB storage device that contains the upgrading files.
Select the check box of the channel that you want to upgrade. Step 4
Click Start Upgrade. Step 5
If the upgrading is successful, the system pops up a message indicating the upgrading
is completed.
5.6 Configuring Remote Devices
5.6.1 Adding Remote Devices
This function is available after you have configured the channel type as IP channel as
described in previous section, see "5.5.5 Configuring Channel Type."
You can add remote devices by adding the IP address.
Select Main Menu > CAMERA > REGISTRATION > Registration, the Registration interface
is displayed. See Figure 5-76.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
