Dahua DH-XVR1B08 User Manual

Local Configurations 115
The CHANNEL TYPE interface is displayed. See Figure 5-74.
Figure 5-74
Configure the channels. Step 2
 Analog Channel: Select the transmission medium such as CVI, CVBS, and then
follow the onscreen instructions to complete the settings.
 IP Channel: You can enable the IP channels by disabling the corresponding analog
channels. The Device also provides expanded IP channels for your use, such as
the 17–24 channels in Figure 5-74.
 The 17–24 channels are only for IP camera and the range changes dependent on
the model you purchased.
 The channel selection for analog camera or IP camera are in sequence, for
example, if you want to select channels for IP camera, you need to select from the
last channel number Channel 16 first, which means, you cannot jump to select the
channel 15 directly until you have selected the channel 16.
Click Apply and follow the onscreen instructions to complete the settings. Step 3
5.5.6 Upgrading Coaxial Camera
Select Main Menu > CAMERA > COAXIAL UPGRADE. Step 1
The COAXIAL UPGRADE interface is displayed. See Figure 5-75.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
