Local Configurations 112
Click Copy to copy the settings to other channels.
5.5.2.3 Encode Enhancement
Only some series products support encode enhancement.
Enabling or disabling this function will take effect after the device is rebooted.
This function is disabled by default. After it is enabled, when main stream resolution is 4K, the
frame rate can be 10 fps.
Select Main Menu > CAMERA > ENCODE > Encode Enhancement. Step 1
The Encode Enhancement interface is displayed. See Figure 5-71.
Figure 5-71
Click behind Encode Enhancement, to enable this function.
Step 2
5.5.3 Configuring Overlay Settings
You can configure to display system time and channel name on each channel window in the live
view screen.
Select Main Menu > CAMERA > OVERLAY > Overlay. Step 1
The Overlay interface is displayed. See Figure 5-72.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dahua DH-XVR1B08 and is the answer not in the manual?

Dahua DH-XVR1B08 Specifications

General IconGeneral
Audio Input1 channel, RCA
Audio Output1 channel, RCA
Video Output1 HDMI, 1 VGA
USB2 USB 2.0 ports
Power SupplyDC12V/1.5A
Video CompressionH.265/H.264
Analog Camera Input8 channels, BNC
IP Camera Input8
HDD1 SATA port, up to 6TB
Network1 RJ-45 port (10/100 Mbps)
Operating Temperature-10°C to +55°C
Operating Humidity10% to 90%
Max Recording Resolution1080N/720p/960H/D1/CIF
