Dahua DH-XVR1B08 User Manual

Local Configurations 132
5.7.1 Enabling Record Control
 Manual recording operation requires the user have the permission to access STORAGE
settings.
 Check to ensure the HDD installed in the Device has been formatted properly.
To enter the record control interface, do the following:
Right-click on the live view screen, the shortcut menu is displayed. On the shortcut Step 1
menu, select Manual > Record Control.
The RECORD interface is displayed, see Figure 5-94.
Figure 5-94
Configure the settings for the record control parameters. See Table 5-31. Step 2
Parameter
Description
Channel
Displays all the analog channels and the connected digital channels.
You can select a single channel or select All.
Record status
Auto: Automatically record according to the record type and

recording time as configured in the recording schedule.
Manual: Keep general recording for 24 hours for the selected

channel.
Stop: Do not record.

Snapshot status
Enable or disable the scheduled snapshot for the corresponding
channels.
Table 5-31
Click Apply. Step 3

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
